Weight | 12 g |
Depth | 70 mm |
Width | 22 mm |
Height | 10 mm |
Series | N |
Part | USB-N13 |
Brand | Asus |
Leds | Link, Activity, Power |
Model | USB-N13 |
Antennae | 2 on-board PCB antenna |
Frequency | 2.4 GHz |
Work Mode | Ad-Hoc, Infrastructure |
USB Connector | USB 2.0 |
Transmit Power | b mode: 18 dBm, g mode: 15 dBm, n mode: 15 dBm |
Supported Protocols | IEEE802.11b/g/n |
Modulation Technology | OFDM: BPSK, QPSK, 16-QAM, 64-QAM, DBPSK, DQPSK, CCK |
Maximum Wireless Transmission Rate | 300 Mbps |
Storage Humidity | 15 % - 95 % RH non-condensing % |
Operating Humidity | 15 % - 95 % RH non-condensing % |
Storage Temperature | -10DegC - 70DegC degree C |
Operating Temperature | 0DegC - 45DegC degree C |
Operating System | Windows 2000, Windows XP x86, Windows XP x64, Windows Vista x86, Windows Vista x64, Windows 7 x86, Windows 7 x64, Mac 10.3, Mac 10.4, Mac 10.5, Mac 10.6, Linux: Redhat 9.0 (Kernel 2.4.20), Ubuntu 9.04 (Kernel 2.6.28-11), Fedora10 (Kernel: 2.6.27.5-117) |
Indoor | 150 m |
