VPN | IPSec, PPTP, L2TP Pass-through |
SSID Support | Multiple SSID Support |
Certification | CE (EN55022/EN55024/EN300 328/EN301489 |
Other Features | Web-based GUI for Configuration, Firmware upgrade, Code lock to prevent improper firmware upgrade, Telnet, Syslog monitoring, TR-069 Client, Wireless Transmission Power: 20 dBm |
Number of USB Ports | 0 |
LAN | RJ-45 |
WAN | RJ-11 |
Antennae | External |
Antennae Capacity | 20dBm Wireless Antenna |
Number of Antennae | 1 |
Number of LAN ports | 4 |
Number of WAN ports | 1 |
Depth | 115.93 mm |
Width | 195.5 mm |
Height | 36.55 mm |
Compatible ISP | BSNL,MTNL,Airtel,Tata broadband and Reliance Broadband |
Color | Black |
Type | Wireless With Modem |
Brand | D-Link |
Model | DSL-2730U |
Controls | Factory Reset Button, WPS Button, Wireless On/Off Switch, Power On/Off Switch |
In The Box | Wireless 150 ADSL2 Router, CD(Manual), Quick Start Guide, Power Adapter, Ethernet Cable, Phone cable, Splitter & Non-Removable Antenna |
Part Number | DSL-2730U |
LED Indicator | Power, LAN, WLAN, DSL, Internet, WPS |
Installation Features | Universal Plug and Play, Installation Wizard, Web-based GUI for Configuration, Firmware Upgrade |
Frequency Band | Single Band |
Frequency | 2.4 GHz |
Temperature | Operating: 0DegC - 40DegC, Storage: -20DegC - 70DegC degree C |
Operating Humidity | Storage: 5 % - 95 % Non-condensing |
Power Supply | AC 12 V/0.5 A |
Firewall | Built-in NAT, Stateful Packet Inspection (SPI), , Denial of Service Prevention, Packet filtering (IP/ICMP/TCP/UDP), Intrusion Detection System (IDS), DMZ |
Encryption | 64/128 bits WEP, WPA/WPA2 |
Other Security Features | Dynamic Host Configuration Protocol (DHCP), Static Routing, Parental Control (URL Blocking, Scheduling), PVC/VLAN Port Mapping, IGMP Snooping with 32 Multicast Groups, Authentication: MAC Address Access Control, Syslog Monitoring |
Standard IEEE | IEEE 802.11b/g, IEEE 802.11n, IEEE 802.11e |
LAN/WAN | 10/100 |
Wireless Speed | 150 Mbps |
Operating System | Windows 98 SE, Windows ME, Windows 2000, Windows XP, Windows Vista |
