VPN | PPTP, L2TP, IPSec Pass-through |
SSID Support | Multiple SSID Support |
Certification | CE, FCC, RoHS |
Other Features | Management: Web Based Configuration (HTTP), Remote Management, Command Line Interface, SSL for TR-069, SNMP v1/2c, SNMP Over EOC, SNMP v1 / 2c, Web Based Firmware Upgrade, Diagnostic Tools, Port Forwarding: Virtual Server, Port Triggering, DMZ, ALG, Advanced Features: Ethernet WAN (EWAN), Guest Network, Wireless Schedule, Traffic Shaping (ATM QoS) UBR, CBR, VBR-rt, VBR-nrt, PVC / Ethernet Port Grouping, Static Routing, DNS Relay, DDNS, IGMP snooping V1/2, IGMP Multicast, UPnP |
USB | 2 |
Number of USB Ports | 5 |
LAN | RJ-45 |
WAN | RJ-11 |
Antennae | External |
Antennae Capacity | 1 x 5 dBi Omni Directional, Undetachable Reverse SMA Antenna |
Number of Antennae | 1 |
Number of LAN ports | 4 |
Number of WAN ports | 1 |
Weight | 300 g |
Depth | 128 mm |
Width | 182 mm |
Height | 35 mm |
Compatible ISP | BSNL,MTNL,Airtel,Tata broadband and Reliance Broadband |
Supported Software | Microsoft Internet Explorer Fire Fox Or Safaribrowser For Web Based Confurigation |
Color | White |
Series | TD |
Type | Wireless With Modem |
Brand | TP-Link |
Model | TD-W8901N 150Mbps Wireless N ADSL2+ Modem |
Controls | Power On/Off Button, Wi-Fi ON/Off Button, Reset Button |
In The Box | TD-W8901N, External Splitter, RJ-11 Telephone Cable, RJ-45 Ethernet Cable, Quick Installation Guide, Resource CD, Power Adapter |
Part Number | 1711502103 |
LED Indicator | Power, ADSL, Internet, WLAN, LAN 1-4 |
Installation Features | UPnP Support, Wi-Fi Protected Setup (WPS) |
Operating Range | 50 m |
Frequency Band | Single Band |
Bandwidth | 40 MHz |
Frequency | 2.4 GHz |
Temperature | Operating: 0DegC - 40DegC, Storage: -40DegC - 70DegC degree C |
Operating Humidity | Operating: 10 % - 90 % Non-condensing, Storage: 5 % - 90 % Non-condensing |
Power Consumption | 5 W |
Power Supply | Input: DC 9 V, 0.6 A |
Firewall | NAT (Network Address Translation), SPI, MAC Address Filtering / IP Address Filtering / Packet Filtering / Application Filtering / URL Filtering, Denial-of-service (DoS), SYN Flooding, Ping of Death |
Encryption | 128-bit WEP, WPA2-PSK, Wireless MAC Filtering, 64-bit WEP, WPA-PSK |
Other Security Features | NAT (Network Address Translation), SPI, MAC Address Filtering / IP Address Filtering / Packet Filtering / Application Filtering / URL Filtering, Denial-of-service (DoS), SYN Flooding, Ping of Death |
Standard IEEE | IEEE 802.3u, IEEE 802.3, IEEE 802.11b/g/n |
DSL Modem Speed | 10 Mbps |
LAN/WAN | 10/100 Mbps |
Wireless Speed | 150 Mbps |
Operating System | Mac OS, ME, NT, NetWare, 8, Linux, Windows: 95, 2000, 98 SE, Unix, XP, 7, Vista |
