Brand | WD |
Series | Caviar Blue |
Model ID | WD10EZEX-75WN4A0 |
Form Factor | 3.5 inch |
Device | Desktop |
Device Type | 3.5 inch HDD |
Drive Capacity | 1 TB |
Spin Speed | 7200 rpm |
Interface | SATA |
Reliability | 300000 (Load/Unload Cycles) |
Cache Memory | 64 MB |
Data Transfer Rate (To/From Host) | 126 Mbps |
Non-recoverable Read Error | 1 per 10^14 |
Power Consumption | 7.3 W (Read/Write), 0.7 W (Standby/Sleep) |
Standard Input Voltage | 12 V DC |
Idle | 6.1 W |
Maximum Start Current | 2.8 A |
Dimensions | 101.6 mm x 26.1 mm x 147 mm |
Weight | 0.69 g |
Operating Temperature | 0DegC to 60DegC |
Non-Operating Temperature | -40DegC to 70DegC |
Shock Tolerance | 65 Gs for 2 ms (Operating), 300 Gs 1 for ms (Non-Operating) |
Cool Operation, NoTouch Ramp Load Technology, IntelliSeek, Formatted Capacity: 1000204 MB, User Sectors per Drive: 1953525169, SATA Latching Connector, RoHS Compliant, Idle Mode Acoustics: 28 dBA, Seek Mode Acoustics: 33 dBA |
