Intel DH61WW Motherboard

Name: Intel DH61WW Motherboard
Brand: Intel Motherboards
Availability: InStock
Rating: 4.5 (600 reviews)

Intel DH61WW Motherboard Share on

Intel Motherboards

₹9310.00

₹9310.00

Go to store

Latest Motherboards

Intel Motherboards

MSI Z370 Tomahawk DDR4 Motherboard

₹21000.00

Zebion Motherboards

Intel DBS2600CW2 Chipset Dual Socket R3 (LGA2011v3) DDR4 RAM Server Motherboard

₹45000.00

Intel Motherboards

Intel Desktop Board DZ77GAL-70K Motherboard

₹17500.00

Intel Motherboards

Intel DH61WW Motherboard Specifications

General

Brand	Intel
Model ID	DH61WW
Packaging	OEM

Essentials

Form Factor	Micro-ATX
Socket Type	LGA 1155
Compatible Processors	Intel Core i7 Processors, Intel Core i5 Processors, Intel Core i3 Processors, Intel Pentium Processors
Chipset	Intel H61
Chipset Manufacturer	Intel

Connectivity

Ethernet Controller	Intel 82567V Gigabit
Ethernet Features	10/100/1000 Mbps

Memory

Number of Memory Slots	2 Slots
Memory Configuration	16 DDR3 Dual Channel DIMM
Memory Frequency	1066 MHz, 1333 MHz
ECC Support	Non-ECC
Buffered Memory	Unbuffered

Storage

SATA 1.5 Gb/s	Intel H61
SATA 3 Gb/s	Intel H61 Express Chipset

Audio

Audio Codec	Realtek ALC892
Audio Channels	6
Audio Features	Intel HD Audio

Graphics

Integrated Graphics card

Intel Graphics

Expansion Slots

PCI Slots	1
PCIe x1 Slots, Generation	1, 2.x
PCIe x16 Slots, Generation	1, 2.x

Internal I/o Headers

SATA 3 Gb/s Headers	4
ATX Power Connectors	1 (8 Pin ATX 12V Power Connectors)
SATA 1.5 Gb/s Headers	4
USB 2.0 Headers	1
Fan Headers	1 (Processor Fan Headers), 1 (System Fan Headers)
Front Panel Headers	3
Other Connectors	S/PDIF Header, Chassis Intrusion Header, Standby Power LED, Low Pin Count (LPC) Debug Header, Front Panel USB 2.0 Headers, Front Panel Audio Header

Back Panel Ports

USB 2.0 Ports, Controller	4
VGA/D Sub Ports	1
Audio I/O Channels	6
RJ-45 Ethernet Jacks	1
Optical S/PDIF Ports and S/PDIF Out ports	1 (S/PDIF Out Ports)
PS/2	1

General Features

Hardware Monitoring	Hardware Monitoring through the Nuvoton I/O Controller, Voltage Sense to Detect Out of Range Power Supply Voltages, Thermal Sense to Detect Out of Range Thermal Values, Two Fan Headers, Two Fan Sense Inputs used to Monitor Fan Activity, Fan Speed Control
BIOS	Intel BIOS, SMBIOS
Features	Energy Star 5.0
Advanced Technologies	Intel HD Audio Technology
Advanced Features	ACPI-compliant Power Management Support

Dimensions

198.12 x 243.84 mm

Disclaimer: Specifications shown may be different from the actual product. We cannot guarantee that the information provided on this page is 100% correct. Please check with the retailer before purchasing.
