Detailed Specifications
General Details
| Inverter Type |
Square Wave Inverter |
| Volt Ampere Rating |
Below 1000VA |
| Recharge Time |
10-12 Hrs. |
| Frequency (Mains Mode) |
Same as Input (45-55 Hz.) |
| Output Voltage (UPS Mode) |
200V-230V 10% |
| Frequency (UPS Mode) |
50 Hz 0.1 Hz |
| Protection |
Battery Deep Discharge, Reverse Polarity, DC Overvoltage |
| Voltage (Mains Mode) |
100V~300V (Wide input voltage range), 180V~260V (Normal input voltage range) |
Other Features
| Technology |
SMD Technology for reliable and compact design |
| Battery Charging |
Battery charging commences even at as low as 120 Volt Mains voltage |
| Switching from Mains to UPS & from UPS to Mains |
Automatic |
| Output Waveform on UPS Mode |
Sine Wave |
| Battery Charging Current |
Constant Charging Approx 10% of The Rated Battery Current in AH |
| Charger |
Constant Current, Constant Wattage |
Alarms
| Low Battery Trip |
Beeps Continuously for 10 seconds |
| Charging Fuse Blown |
Beeps Continuously for 10 seconds |
| Overload |
Beeps Continuously for 10 seconds |
| Low Battery (Pre Alarm) |
Beeps every 10 seconds |
| Mains to UPS |
Beeps every 2 seconds for 5 times |
| No Load Shut Down |
Beeps Continuously for 10 seconds |
| Short Circuit |
Beeps Continuously for 10 seconds |
